Kluson 3 Per Side Prestige Series Vintage Vertical Mount Open Bronze Gear Tuning Machines
$153.90
SKU: KP24-3V
- Specifications
- Base Plate material= Zinc Diecast
- Worm Gear material= Stainless Steel
- Ring Gear material= Bronze
- Gear ratio= 18:1
- String Post Orientation= Vertical for drilled Pegheads
- String Post Overall length= 1 1/16 in. (27mm w/ domed top)
- String Post Diameter= 1/4 in. (6.35mm)
- String thru hole location= 13/16 in from baseplate
- Mounting hole spacing= 24mm (Vintage Kluson)
- Configuration= 3 + 3
- Mounting hardware included= screws and bushings
- Bushing Dimensions= 6.5mm I.D. / 8.75mm O.D.
- Bushing Type= Hex head push-in
- Description
These tuning machines are created especially for drop in replacement of old Kluson® tuning machines from the 30’s and 40’s with a 1/4 in. string post diameter. While they look the same, they feature a diecast base, bronze ring gear, stainless worm gear with close tolerance bushings, and 18:1 gear ratio. For solid headstocks with vertical mount.
- Specifications
- Base Plate material= Zinc Diecast
- Worm Gear material= Stainless Steel
- Ring Gear material= Bronze
- Gear ratio= 18:1
- String Post Orientation= Vertical for drilled Pegheads
- String Post Overall length= 1 1/16 in. (27mm w/ domed top)
- String Post Diameter= 1/4 in. (6.35mm)
- String thru hole location= 13/16 in from baseplate
- Mounting hole spacing= 24mm (Vintage Kluson)
- Configuration= 3 + 3
- Mounting hardware included= screws and bushings
- Bushing Dimensions= 6.5mm I.D. / 8.75mm O.D.
- Bushing Type= Hex head push-in
- Description
These tuning machines are created especially for drop in replacement of old Kluson® tuning machines from the 30’s and 40’s with a 1/4 in. string post diameter. While they look the same, they feature a diecast base, bronze ring gear, stainless worm gear with close tolerance bushings, and 18:1 gear ratio. For solid headstocks with vertical mount.
